Gems Ls-2050 W/Ep Side-Mounted Level Switch 240v

Gems Ls-2050 W/Ep Side-Mounted Level Switch 240v
Gems Sensors Division
Gems Sensors Inc.
Control Flow
Side-Mounted Level Switches
Model No: Ls-2050 W/Ep
Elect.Rating: 20 Va
Max.Press: 6205 Kpa
Code Ident: 04034
008 13
Level-Switch
Type No/Series: Ls-2050
P/N: 55690
Pilot Duty
20 V.A. 50 To 240 Vac
U.S. Pat No: 3749864
30b
P/N: 56270
Rev: B
Standard Versions: 30290
Switch: Spdt
Stem & Mtg Material: Brass
316 Ss
Other Wetted Materials: Beryllium Copper, Teflon, Ceramic
Operating Temp °F:
Water: To +180°F
Oil: -40° To +250°F
Psig, Max. @ 70°F: 150
Mounting Attitude: Horizontal: ±15°
Switch Differential (In Liquid): 1/2″ Min.
Liquid Specific Gravity: .8 Min.
Lead Wires: #18 Awg, 24″ L., Polymeric
Float Material: Buna N
316 Ss
Other Wetted Materials: Ss, Teflon, Ceramic
Operating Temp °F: -40°F To +300°F
Psig, Max. @ 70°F: 900
Switch Differential (In Liquid): Approx. 3/4″
Liquid Specific Gravity: .9 Min.
Item: 30067896
Part Number: 966134
Descricao Detalhada/Detailed Description: Flow Switch Level Subapplication Sistema/System Hpu Application Compensator Model
Aplicacao/Application: Spare Para Hpu Do Compensador Dsc 25 600k/ Spare For Dsc 25 600k Compensator Hpu
Weight : 2.040 Kg
Ref No : 182953
