Foxboro Iap10-t20c1f-m1 Pressure Transmitter 42 V

Foxboro Iap10-t20c1f-m1 Pressure Transmitter 42 V
Foxboro
Invensys Systems Inc.
Model: Iap10-t20c1f-m1
Supply: 12.5-42 Vdc
Cal.range: 10-20 Psig
Origin: 2a0838
Ps/mwp= 30 Psia
Explosion-proof Cl.i, Gp. B,c,d:
Cl.ii, Gp.e, F & G: Cl.iii
T5 @ 85˚c Max.amb., T6 @ 80˚c Amb.,
Cl.i, Ii, Iii Dv 1, Gps A,b,c,d,e,f,g
Ni Cl.i, Dv 2, Gps A,b,c,d, S Cl.ii, Iii, Dv 2, Gps F & G
T4 @ 85˚c Max Amb; T4a @ 40˚c Max Amb
Cl,i, Zn 0, Aex Ia Iic T4 (-40˚c Ta 85˚c)
Cl.i, Div 1, Gps A,b,c,d; Cl.ii Dv 2, Gps E,f & G;
Cl Iii; T3c @ 85˚c Max Amb; T4a @ 40˚c Max Amb
Ex Ia/ex Na Iic T3 (-40˚c Ta 85˚c), T4 (-40˚c Ta 40˚c);
Ip66; Cl Ii, Div 1, Gps E,f & G
Csa 1042437x
Sen.id: Nca49c230a
Origin: 0834
Mat’l: 316l-c0-ni
Connector: 1/4-1/2 Npt
D0162vt/ J
Pwa D0149gh/ G
Pwa D0149gj/ K
S/w Ver: 5.00
Electronic Module
Replacement Part Number: D0162vz
D0149yb-h
Sf080626.669
Weight : 1.400 Kg
Ref No : 148268
