Elcon 1090-g-0-0720-aa Series 1000 Strain Gauge Converter Used

Elcon 1090-g-0-0720-aa Series 1000 Strain Gauge Converter Used
Elcon Instruments
Cat No.: 1090-g-0-0720-aa
Max Amb. Temp. 55°C 250 Um
[Eex Ia] Iic-cesi Ex-90.C.117 X
(Ex Ia) Iic-aus Ex 1288 X
Series 1000 Strain Gauge Converter
Instrument Type 1090
Intrinsic Safety Output Data
Uo 18.5V
Io 185 Ma
Co 0.4µF
Co 0.9 Mh
Lo/R 43µH/Ω
Sensor Type Strain Gauge
6 Wire Bridge 10 Vcc
Input 0÷20 Mv
Output 4÷20 Ma
D.96C.155 Ex Ia Iic
Cc=0.125µF Lc=0.5 Mh
Ci=0.12µF Li=0.9Mh
Cl. I, Div. 2, Gr. A,B,C,D
Cl. Ii, Gr. E,F,G;
Cl. Iii
Supply 24 Vdc
Is Max. 125 Ma
Made In Italy By Elcon Instruments
Weight: 230 Gm
