Dell L305p-01 Switching Power Supply 305w

Dell L305p-01 Switching Power Supply 305w
Dell
Model No.: L305p-01
P/N: Nh493
P/N: Ps-6311-5df-Lf
Dc Output: 305w
Input: 100-120v~/9a 50-60hz
200-240v~/4.5a 50-60hz
Output: +5v —/22a Max -12v — /1a Max
+5v(Fp)—/4a Max +3.3v — /17a Max
+12va—/18a Max +12vb —/ 18a Max
Combined Power On +3.3v And +5v Rails Not Exceed 150w.
Combined Power On +12va And +12vb Rails Not Exceed 264w.
Max. Continuous Total Dc Output Power Shall Not Exceed 305w.
Ambient: 50°C Max.
(Switching Power Supply/Exchange Power Supply)
Level 3
E132068
Cn- 0nh493-71615-7co-3168
Rev. A05
Made In China
Weight : 1.760 Kg
Ref No : 190264
