Dell H875ef-00 Power Supply Workstation 240v

Dell H875ef-00 Power Supply Workstation 240v
Dell
High Efficiency Electronics (Dongguan) Co., Ltd.
Model: H875ef-00
P/N: D875e001l
Dp/N: J556t
Ac Input (50-60hz): 100-240v~/12.5a
Dc Output/Dc Input (Output): +5v—/32a, +3.3v—/30a
+12va—/18a, +12vb—/18a
+12vc—/18a, +12vd—/18a
+12ve—/18a,
-12v—/0.5a, +5vsb—/4a
The Total Output Power Of +5v And +3.3v Does Not Exceed 225w
The Total Output Power Of +5v And +3.3v Does Not Exceed 225w
+12va,+12vb,+12vc,+12vd And +12ve Shall Not Exceed 825w
The Total Output Power Of +12va, +12vb, +12vc, +12vd And +12ve Does Not Exceed 825w
The Total Output Power Of +12va, +12vb, +12vc, +12vd And +12ve Does Not Exceed 825w
Max. Output Power: 875w
Maximum Input (Output) Power: 875w
Level 3
E143709
Fj-03-1
D875e001l-Dl01-A0
M1a390201477
Made In China
Weight : 2.270 Kg
Ref No : 168749
