Cegelec Alspa C80-35 Power Supply Programmable Controller 24v

Cegelec Alspa C80-35 Power Supply Programmable Controller 24v
Cegelec Controls
Alspa C80-35
High Capacity
Power Supply
Programmable Controller
Input: 100-240 Vac~
50/60hz 100va
125vdc—, 50w
Output: 24vdc—
0.8a Max.
Torque 12 In-Lb.
Use Copper Conductors Rated Or 75 Deg. C Only.
Ce693pwr330c
120/240vac Hi-Cap 30w
E157515
Temp. Code T4
3922114
826
Fip Fieldbus Dual Channel Control Fip Ch 2 1mhz
Rs-422
Fip Controller
Ic693bem340-Cc
Temp. Code T4a
3612873
817
Input
24vdc—
Pos/Neg Logic
7.0 Ma/Pt At 24vdc—
32 Pt Pos/Neg Fast
Ic693mdl655e
3455272
813
Output
5/12/24vdc—
Neg Logic
25ma Max/Output At 5vdc—
0.5a Pilot Duty
At 12/24vdc—
Ic693mdl752e
Ttl 32pt
3542673
829
High Density Analog Current Input
Alg223
Mae 96-07
Al_mri
Ic693alg223c
Input Analog 16pt Current
3705562
810
Alg220
Ic693alg220f
Input Analog 4pt Voltage
3740750
825
Rtd Input
He693rtd600r
E180220
Electrical Ratings: 100ma, 5 Vdc 6 Channel. Accuracy I 0,5
Degrees C Typical, +/-1.0 Degrees C For Cu-10 And Td5r
Max.Amb.Temp: 60 Degrees C
Filter Module
Ic693acc310a
Base 10-Slot With Cpu
Bc3d2
Ic693cpu323r
3723992
3814
Made In Usa
Weight : 4.440 Kg
Ref No : 187835
