| Attribute | Value |
|---|---|
| Brand | Castel |
| Model Type | 1079/11 |
| Refrigerant Compatibility | CFC, HCFC, HFC |
| MOPD | 21 Ac / 19 Dc Bar |
| Temperature Range (Ts) | -35°C to +105°C |
| Pressure (Ps) | 45 Bar |
| Type | HM2 |
| Voltage | 220-230V~ |
| Frequency | 50-60 Hz |
| Power | 8W |
| Tu | 50°C |
| Cl/Ci | H |
| Product Code | 571.09.000.029 |
| Description | Castle Solenoid Valve Complete for Liquid |
| Variant | Castle HM2 230V/60Hz 1 3/8″ 1079/11 |
| Store | Forw Store |
| Country of Origin | Made in Italy |
| Weight | 2.290 Kg |
What is the Castel 1079/11 Solenoid Valve?
The Castel 1079/11 is an electromechanical solenoid valve that is mainly utilized in refrigeration and air conditioning systems. Its main purpose is to regulate the flow of refrigerant by opening or closing upon receiving an electrical signal. This on-off control is necessary for system efficiency, safety, and accurate regulation.
This specific model is part of the Castel 1079 series, one of the renowned brands for having high-performance capabilities, strong builds, and having a wide scope of applications.
Key Features
Some of the key features that make the Castel 1079/11 valve a reliable component include:
Compact but long-lasting construction
Designed to withstand high pressures and continuous running.
High-performance materials
Crafted from brass body and stainless steel internal components to ensure resistance against corrosion as well as enduring usage.
Suitable for a range of refrigerants
Works with a wide range of common refrigerants including R134a, R404A, R407C, R410A, R507, and more.
Direct-acting type
Ensures fast and reliable response to electrical control signals.
Normally closed valve
Stays closed when de-energized, preventing unwanted refrigerant flow.
Threaded connections
Easy to install in most systems using standard threaded fittings.
Technical Specifications
Here’s a quick look at some key technical specs of the 1079/11 model:
Connection size: 1/4” SAE flare
Max operating pressure: Up to 45 bar (652 psi)
Voltage types: Usually comes in 220-240V AC or 24V AC/DC
Type of coil: Suitable for Castel coils – model 9300 or equivalent
Temperature range: -40°C to +80°C
Mounting orientation: Any orientation, ideally coil facing up
Uses of Castel 1079/11
The solenoid valve is utilized across a range of industries owing to its adaptability and dependability:
Refrigeration systems
Regulates refrigerant flow in commercial refrigeration units such as cold rooms and display cabinets.
HVAC systems
Applied in split AC systems, chillers, and ventilation equipment for effective thermal management.
Industrial refrigeration
Ideal for food storage on a large scale, dairy, and pharmaceutical use where temperature control is paramount.
Heat pumps
Aids in reversing the direction of refrigerant flow for heating and cooling operations.
Advantages of Utilizing Castel 1079/11
Energy efficiency
Prevents wastage of energy by managing refrigerant flow effectively.
System protection
Protects against flooding of the compressor and pressure imbalance by closing during system shutdown.
Low maintenance
Durable design = less breakdown and longer time between service.
Versatility
Applicable in new installations as well as a replacement component.
Worldwide availability
Castel products are available widely and backed, making easy replacement and service possible.
