Allen-Bradley Rockwell Automation 25b-D4p0n104 Powerflex 525 Power Module 480v

Allen-Bradley Rockwell Automation 25b-D4p0n104 Powerflex 525 Power Module 480v
Allen-Bradley
A-B Quality
Rockwell Automation
Delta Electronics, Inc.
Ethernet/Ip
Powerflex 525
Power Module
Cat No: 25b-D4p0n104
Ser/Series: A
Fw: 7.001
Ip20 / Ul Open-Type (Rated -20°C To
50°C Ambient)
Ip20 / Ul Open-Type With Top Fan Kit
Installed (Rated -20°C To 70°C Ambient)
Ip30 / Nema 1/Ul Type 1 With Top Cover
And Optional Conduit Box Kit
Installed (Rated -20°C To 45°C Ambient)
Power: 1.5kw/2.0hp
Input: 3 Phase, 380-480v, 47-63hz
Ac Voltage Range: 323-528
Output: 3 Phase, 0-500 Hz
Ac Voltage Range: 0-460
Continuous Amps: 4.0
60 Sec Ovid Amps: 6.0
Short Circuit Current: 100ka
Power Terminal Wire:
Use 75°C Cu Wire (Use 90°C Cu Wire If
Greater Than 50°C Ambient)
0.8 Mm² – 5.3 Mm² (18-10 Awg)
Torque 1.96 Nm (17.4 In.-Lbs.)
Pn-164057
2083541
Ii (2) Gd
Tuv 12 Atex 7199 X
E59272
Control Module
Cat No: 25b
Mac Id: 5c881600d27c
Asa: 705d8bd3
Dc Brushless
Model: Afb0512vhd
3620510611
Dc12v 0.24a –Se24
Abl6
2945455902
Made In China
Product Of China
Weight : 1.080 Kg
Ref No : 161429
