| Attribute | Value |
|---|---|
| Brand | Allen-Bradley |
| Catalog Number | 22F-D1P5N113 |
| Series | A |
| Enclosure | IP20 / UL Open-Type (Rated -10ºC to 50ºC ambient) |
| User Manual | Refer to user manual |
| Motor Rating | 0.4 kW / 0.5 HP |
| Input | 3 Phase, 380~480V, 48~63Hz |
| AC Voltage Range (Input) | 342~528 V |
| Input Amps | 1.8 A |
| Output | 3 Phase, 0~400Hz |
| AC Voltage Range (Output) | 0~460 V |
| Continuous Output Amps | 1.5 A |
| 60 Sec Overload Amps | 2.1 A |
| Short Circuit Current Rating | 100 kA |
| Power Terminal Wire | Use 75ºC CU Wire |
| Torque | 1.47 Nm (13.02 in-lbs) |
| Product Line | PowerFlex 4M |
| Country of Origin | Made in China |
| Weight | 1.370 kg |
What Is the Allen-Bradley PowerFlex 4M AC Drive?
The PowerFlex 4M line of drives from Allen-Bradley is a space-saving, economical line of drives intended for simple motor control applications. The 22F-D1P5N113 is among the more common models within this line and provides reliable operation in a low-profile package.
This drive is engineered to provide reliable control for three-phase induction motors across a range of industrial applications. It has simple installation, programming, and maintenance, making it the preferred choice for small machine manufacturers and large industrial plants.
Major Specifications of the 22F-D1P5N113
Input Voltage: 100-120V AC, single-phase
Output Power: 0.5 HP (Horsepower)
Output Current: 1.5 Amps
Frequency Range: 0–400 Hz
Control Method: V/Hz and sensorless vector control
Enclosure: Open Type (IP20)
Interface: Integrated keypad with LED display
The 22F-D1P5N113 unit is a tried-and-tested solution for low-horsepower applications where small size is required without compromising performance or functionality.
Key Features
Space-Saving Design
Since the PowerFlex 4M has a small footprint, it can easily be integrated into panels with limited space. This is particularly useful in OEM and retrofit applications.
Flexible Programming
The easy-to-use keypad interface facilitates efficient setup and parameter adjustment. It is also remotely programmable through Connected Components Workbench software.
Energy Efficiency Care:
Designed to provide precise motor speed control, the drive assists in saving energy and minimizing mechanical wear on motor-driven systems.
Global Compatibility
The drive is compatible with global voltage ratings and standards, which makes it suitable for various applications in international markets.
Built-in Protection Features
It has motor overload protection, under-voltage and over-voltage protection, and fault diagnostics for safe operation.
Applications of PowerFlex 4M 22F-D1P5N113
This drive is perfectly suitable for many low-power industrial applications such as the following:
Fans and Blowers
Changing airflow in response to need and optimizing energy consumption.
Pumps
Ideal for applications in water treatment, HVAC, and chemical processing.
Use for variable speed speed requirements.
Conveyors
Smooth start/stop and changes in speed in packaging, food processing, and material handling.
Mixers and Agitators
Accurate speed control improves mixing consistency and effectiveness.
Why Select Allen-Bradley?
Allen-Bradley, a Rockwell Automation brand, is an internationally recognized leader in industrial automation. Drives from Allen-Bradley are recognized for their resilience, ease of use, and effortless integration into a Rockwell control system. The PowerFlex 4M series, of which the 22F-D1P5N113 is a member, is a continuation of this tradition of quality and dependability.
