Allen-bradley A-b Quality 2094-bsp2 Bulletin 2094 Shunt Module 460v

Allen-bradley A-b Quality 2094-bsp2 Bulletin 2094 Shunt Module 460v
Allen-bradley
A-b Quality
Kinetix
Guard Motion
6000
Bulletin 2094 Shunt Module
Cat.no.: 2094-bsp2
Ser./series: A
200/460v System
200w Internal
Max Short Circuit: 100,000a
Instruction Manual: 2094-in001x-xx-x
Minimum Drive Firmware Ver.: V1.068
Buss In: 650 Vdc 201 A Peak 30 A Avg
Control Input (200/230v): 120-425 Vdc 3a
Control Input (400/460v): 100-264 Vac 3a 1ph 50-60hz
Internal Shunt: 28.75 Ohm 200w 28a Peak 2.6a Avg
External Shunt: 4 Ohm (Min) 3600 W Avg (Max) 201 A Peak (Max) 30a Avg (Max)
Wiring Diagram 3412
Product Of Mexico
Weight : 3.170 Kg
Ref No : 142495
