Allen-Bradley A-B Quality 1769-Ob32 Sourcing Output Module 24v

Allen-Bradley A-B Quality 1769-Ob32 Sourcing Output Module 24v
Allen-Bradley
A-B Quality
Compact I/O
Dc Output
24vdc Source
32 Pt. 20.4-26.4vdc Sourcing Output Module
Cat: 1769-Ob32
Ser. A
Rev. 1
F/W Rev: 3.1
Current Rating @ 24vdc
Max. Cont. Amps/Pt:
1.0a @ 30°C
0.5a @ 60°C
Max. Cont. Amps/Com: 8a @ 60°C
Max. Cont. Amps/Module:
16a @ 30°C
8a @ 60°C
Surge: 2a Max. For 10ms Every 2 Sec
Bus Current Draw:
5vdc 0.3a
24vdc 0a
Win (21) 7m7dq5au
Fac. 7m
Power Supply Dist. Rating 6
Product Code T3
Operating Temperature Code T3c
Class I, Div 2, Group A, B, C, D
459020-3580
Right End Cap/Terminator
Cat: 1769-Ecr
Bus Current Draw:
5vdc 0.005a
24vdc 0a
Win (21) 7m5bv9on
459080-0090
Ma459221-2950
Psw1.1
94v-0
3206
Made In Malaysia
Weight : 360 Gm
Ref No : 166000
