Allen-bradley A-b Quality 1769-l32e Compactlogix Processor Unit Ethernet 24v

Allen-bradley A-b Quality 1769-l32e Compactlogix Processor Unit Ethernet 24v
Allen-bradley
A-b Quality
Ethernet Ip
Industrial Compactflash
Compact I/o
Compactlogix
L32e
Logix 5332e Processor Unit
Cat: 1769-l32e Ser.a
F/w Rev: 1.15
Bus Current:
— 5 Vdc .66a
— 24vdc .09a
Power Supply Dist. Rating 4
02341343
Class I, Div 2, Gpoup A,b,c,d
Temp Code T4a
Tamb Max = 60 C
Cat No: 1784-cf64 A
Rev. D01
64 Mb Capacity
Part No: 97235074
Cug40034 Rwkf080826-1
Compact I/o
Power Supply
Cat: 1769-pb4 Ser.a
Rev.3
Line Voltage: 19.2~31.2 Vdc
Max. Line Va Requirement: 100va At 24vdc
Max. Inrush: 30a
Bus Current Out At 60°c:
5vdc 4a
24vdc 1.7a
Win (21) 7m5db4xi
Fac.7m
Operating Temperature Code T3c
459060-0252
Scb216b
Fr4
Dc Input
24 Vdc Sink/source
1769-iq16
Ma459235-0480
Psw2.1
94v-0
4107
Ac/dc Out
16 Pt. 5-265vac, 5-125vdc Form A Relay
Cat: 1769-ow16 Ser.a
Rev.2
F/w Rev: 3.1
Nema Ics 2-125
V.a. Rating (Maximum Per Module): 1440va
Win (21) 7m7gf4pn
Power Supply Dist. Rating: 8
459020-2351
Devicenet Scanner
Cat: 1769-sdn Ser.b
Firmware Rev.: 2.2
Bus Current Draw:
5vdc 0.44a
24vdc 0a
Dnet Pwr 24vdc 110ma Class 2
*sdnb010202*
*1a262218*
Win *02321577*
40869-102
Right End Cap/terminator
Cat: 1769-ecr Ser.a
Rev.1
Bus Current Draw:
5vdc 0.005a
24vdc 0a
Win (21) 7m5cz7ma
459080-0090
Ma459221-2950
Psw1.1
2108
Assembled In Malaysia
Made In Malaysia
Made In U.s.a.
Weight : 1.460 Kg
Ref No(S) : 153129
