Allen-Bradley 25b-D017n104 Powerflex 525 Power Module 480v

Allen-Bradley 25b-D017n104 Powerflex 525 Power Module 480v
Allen-Bradley
A-B Quality
Rockwell Automation
Ethernet/Ip
Powerflex 525
Power Module
Series: A
Cat No.: 25b-D017n104
Ip20/Ul Open-Type (Rated-20°C To 50°C Ambient)
Ip20/Ul Open-Type With Top Fan Kit Installed (Rated-20°C To 70°C Ambient)
Ip30/Nema 1/Ul Type 1 With Top Cover And Optional Condult Box Kit Installed (Rated-20°C
To 45°C Ambient)
Power: 7.5kw/10hp
Input: 3 Phase, 380-480v, 47-63hz
Ac Voltage Range: 323-528
Output: 3 Phase, 0-600hz
Ac Voltage Range: 0-460
Continuous Amps: 17.0
60 Sec Ovld Amps: 25.5
Short Circuit Current: 100ka
Power Terminal Wire:
Use 75°C Cu Wire (Use 90°C Cu Wire If Greater Than 50°C Ambient)
2.1 Mm2-8.4 Mm2 (14-8 Awg)
Torque 1.96 Nm (17.4 In.-Lbs.)
Frn: 5.001
E59272
Ii (2) Gd
Tuv 12 Atex 7199 X
Control Module
Cat No.: 25b
Mac Id: 40410101f56f
Asa: 704dd5ee
H/P
2945455902
Product Of China
Weight : 2.110 Kg
Ref No : 161750
