Allen-bradley 22b-d2p3n104 Drive

Allen-bradley 22b-d2p3n104 Drive
Allen-bradley
A-b
Powerflex 40
Series A
Cat No.: 22b-d2p3n104
Ip20/ul Open-type With Top Cover Removed (Rated- 10°c To 50°c Ambient)
Ip30/nema 1/ul Type 1 With Top Cover And Optiona I Conduit Box Kit
Rated- 10°c To 40°c Ambient
Motor Rating: 0.75kw/1.0hp
Input: 3 Phase, 380-480v, 48-63hz
Ac Voltage Range: 342-528
Amps: 3.2
Output: 3 Phase, 0-400hz
Ac Voltage Range: 0-460
Continuous Amps: 2.3
60 Sec Ovld Amps: 3.45
Short Circuit Current: 100ka
Power Terminal Wire:
Use 75°c Cu Wire
5.3mm2-1.3mm2 (10-16awg)
Torque 1.96nm (17.4 In.-lbs.)
Made In China
Weight : 1.650 Kg
Ref No : 149637
