ALLEN-BRADLEY 100-D110 CONTACTOR SER A

Product Information:

Product Name: ALLEN-BRADLEY 100-D110 CONTACTOR SER A

Manufacturer: ALLEN-BRADLEY

Brand: A-B

Catalog Number: 100-D

Serial Number: A

Model Number: 100-D110

Standards: IEC 60947-4-1, EN 60947-4-1

Voltage Rating (AC-1): 1000V, 250A

Transient Overvoltage (UIMP): 12KV

Maximum Rated Voltage and Current (Enclosed): 600VAC, 160A

Terminal Hardware Type: HF 180

Torque Rating: 10…12NM, 90…110 LB-IN

Recommended Wire Type: Copper (CU) Wire, 75°C Only

Coil Voltage: 105/110 EI

Weight: 3.850 KG

Country of Manufacture: Switzerland

Reference Number (S): 45707

Key Features:

1. High Voltage Rating: This contactor is rated for AC-1 applications up to 1000V and 250A, making it suitable for various industrial purposes.
2. Transient Overvoltage Protection: With a UIMP rating of 12KV, this contactor can withstand transient overvoltages, ensuring its durability in demanding conditions.
3. Enclosed Design: It is designed for enclosed applications, with a maximum rated voltage of 600VAC and a current rating of 160A.
4. Robust Terminal Hardware: Equipped with HF 180 terminal hardware and a torque rating of 10-12NM (90-110 LB-IN), ensuring secure connections.
5. Copper Wire Compatibility: This contactor is intended for use with 75°C copper wires, ensuring safe and reliable electrical connections.
6. Coil Voltage Options: Supports coil voltage of 105/110 EI for flexible voltage control.
7. International Standards: Complies with IEC 60947-4-1 and EN 60947-4-1 standards, ensuring safety and performance.
8. Made in Switzerland: Manufactured in Switzerland, known for its precision engineering and quality.
9. Wide Voltage Range: Compatible with 208V-277V at 250A, suitable for a variety of voltage applications.

Description: The ALLEN-BRADLEY 100-D110 CONTACTOR SER A is a high-quality electrical contactor designed for a wide range of industrial applications. Manufactured by ALLEN-BRADLEY in Switzerland, it adheres to international standards, including IEC 60947-4-1 and EN 60947-4-1, ensuring safety and reliability.

This contactor features a high voltage rating of 1000V and a current rating of 250A in AC-1 applications, making it suitable for controlling heavy loads. It is also equipped with transient overvoltage protection, with a UIMP rating of 12KV, ensuring its resilience in harsh electrical environments.

The enclosed design of this contactor allows for a maximum rated voltage of 600VAC and a current rating of 160A, providing versatility in various applications. Its terminal hardware, designed with HF 180 and a torque rating of 10-12NM (90-110 LB-IN), ensures secure and reliable connections. It is recommended for use with 75°C copper wires, guaranteeing safe electrical connections.

The contactor offers flexibility in coil voltage options with a rating of 105/110 EI, allowing for precise voltage control. Additionally, it can handle voltages ranging from 208V to 277V at 250A, accommodating a variety of voltage requirements.

With its robust construction and adherence to international standards, the ALLEN-BRADLEY 100-D110 CONTACTOR SER A is a reliable choice for industrial electrical applications, providing durability and performance in demanding conditions.
