Af 5000-10 Air Filter 60°C

Af 5000-10 Air Filter 60°C
Air Filter
Af 5000-10
Max. Press: 9kgf/Cm2
Max.Press: 1 Mpa 150 Psi
Max Temp: 60°C (140°F)
Model: Af5000
Port Size: 3/4″ 1”
Max.Supply Pressure Kgf/Cm2: 15
Max.Operating Pressure Kgf/Cm2: 9.9
Ambient And Media Temperature: 5~60°C
Filtration: Standrd: 5µM, Option: 2,10,20,40,70,100 µM
Bowl Material: Polycarbonate
Directions:
Temperature Range: 5-60°C (40-140°F)
Maximum Pressure: 10 Kgf/Cm2
Case Material: P.C.
Weight : 1.010 Kg
Ref No : 168520
