Abb Hd4/W 12.06.32 Circuit-Breaker 12 Kv

Abb Hd4/W 12.06.32 Circuit-Breaker 12 Kv
Made By Abb
Abb Inc.
Circuit-Breaker
Hd4
Hd4/W 12.06.32
Classification: E2, M2, C2
Iec 62271-100
Cei 17-1
Ur Voltage: 12 Kv
Up Lighting Impulse Withstand Voltage: 75 Kv
Ud Power Frequency Withstand Voltage: 28 Kv
Fr Frequency: 50/60 Hz
Ir Normal Current: 630 A
Ik Short Time Withstand Current: 31.5 Ka
Tk Duration Of Short Circuit: 3 S
Isc:
Short Circuit Breaking Current: 31,5 Ka
Making Capacity (Peak Value): 80 Ka
At The Voltage Of: 12 Kv
D.C. Component: Less Than= 35 %
Ic Cable-Charging Breaking Current: 25 A
Prm Sf6 Filling Pressure At 20 C: 0,380 Mpa
Operating Sequence: O-0,3s-Co-15s-Co
Hg00006297
Esh6
Operating Mechanism
-Mc/-Mo1/-Mo2/-Rl1/-Rl2/-Mu/-P 110 V—
-Ms 120 V 60hz
Sf6
Name: C.Stat
200603590
Fas: 000000640167
507893801
00002723200602
1vc1u8h13a01c
1vc1w0881a01c
509155-823
Gen 06
Elt-Abb Pt
506450801
00004313200601
00004311200601
00004289200601
433033-831
Saap Cavi
Type Y1
Ui: 380v~
Ith2: 16 A
Weight : 114.600 Kg
Ref No : 190656
