Circuit-breaker
Hd4
Hd4/c 12.06.25
Classification: E2, M2, C2
Iec 62271-100
Cei 17-1
Ur Voltage: 12 Kv
Up Lighting Impulse Withstand Voltage: 75 Kv
Ud Power Frequency Withstand Voltage: 28 Kv
Fr Frequency: 50/60 Hz
Ir Normal Current: 630 A
Ik Short Time Withstand Current: 25 Ka
Tk Duration Of Short Circuit: 3s
Isc Short Circuit Breaking Current: 25 Ka
Making Capacity (Peak Value): 63 Ka
At The Voltage Of 12 Kv
D.c.component: Less Than = 35%
Ic Cable-charging Breaking Current: 25 A
Prm Sf6 Filling Pressure At 20°c: 0,380 Mpa
Operating Sequence: O-0,3s-co-15s-co
Electrical Diagram: 1vcd400007 (V3035)
Esh6
509155/826
507893801
500027120216h6
1vc1bd00021699
000005544608
P150
I.hd4 Sez 1vcf347161r0141
Type: Y1
Ui 380v~
Ith2 16a
576912-801-nov.00
506450801
001513130424ab
001522130424ab
001520130424ab
Italy
Weight : 115.500 Kg
Ref No : 141079
