Abb Af16z-30-01-21 Contactor 690v

Abb Af16z-30-01-21 Contactor 690v
Abb Stotz-kontakt Gmbh
Af16z
Af16z-30-01-21
24-60v 50/60hz 20-60vdc
-k5
Ui=690v~
Ith=35a
Uimp=6kv
Ieac-1=30a
Ie=18a
Iec/en 60947-4-1
Gb 14048.4
600v Ac 30a
Awg 10-16 Cu 75°c
Torque 13lb.in-1.5nm
Uimp=6kv
Hw02016-15005
041)5292518
A600 Q600
Aux + Coil
Awg 14-18 Cu 75°c
Torque 11lb.in-1.2nm
Coil: Uimp = 1.5kv
600v Ac Max
B C2-19106
Ef19
Ef19-18.9
-f5
5.7-18.9 A
1sax121001r1105
Iec/en 60947-4-1
Iec/en 60947-5-1
Ue=690v Ac
Ui=690v Ac
50/60hz
Ip 20
Gb/t14048.4
Gb/t14048.5
Use 75°c Copper Wire Only
Main Circuit: Awg 16…10
Torque: 7…13 Lb-in/0.8…1.5 Nm
Aux. Circuit: Awg 18…10
Torque: 7…11 Lb-in/0.8…1.2 Nm
Bvs 15 Atex F 001
Ii (2) G [ex Eb Gb] [ex Db Gb] [ex Pxb Gb] Iecex Bvs 17.0016
Ii (2) D [ex Tb Db] [ex Pxb Db] [ex]
B600/q600
Ith=6a
2cdc107043m6801
19026 00031
4 013614 404023
Made In China
Made In France
Weight : 470 Gm
Ref No : 132074
