Abb Af09z-30-01-21 Contactor 690v

Abb Af09z-30-01-21 Contactor 690v
Abb Stotz-kontakt Gmbh
Af09z
Af09z-30-01-21
24-60v 50/60hz
20-60vdc
Ui= 690v~
Ith= 35a
Uimp= 6kv
Ie Ac-1= 25a
Iec/en 60947-4-1
Gb 14048.4
General Use: 600v Ac 25a
Awg 10- 16 Cu 75°c
Torque 13 Lb.in – 1,5nm
A600 Q600
Awg 14-18 Cu 75°c
Torque 11 Lb.in-1,2nm
Coil: Uimp= 1,5kv
600v Ac Max.
C2-18124
Hw02016-15004
041) 529 2518
Ef19
Ef19-2.7
0.8-2.7 A
1sax121001r1103
Iec/en 60947-4-1
Iec/en 60947-5-1
Gb14048.4
Gb14048.5
Ue/ui= 690v Ac
50/60hz
Ip20
Scpd/690 V
Use 75°c Copper Wire Only
Main Circuit: Awg 16…10
Torque: 7…13 Lb-in/0.8…1.2 Nm
Aux. Circuit: Awg 18…10
Torque: 7…11 Lb-in/0.8…1.2 Nm
Trip Amps Are 125% Of Fla
Bvs 15 Atex F 001
2cdc107043m6801
Ii (2) G [ex Eb Gb] [ex Db Gb] [ex Pxb Gb]
Iecex Bvs 17.0016
Ii (2) D [ex Tb Db] [ex Pxb Db]
[ex]
B600/q600
18065 00041
4 013614 404009
Made In France
Made In China
Weight : 480 Gm
Ref No : 119467
