Abb Af09-30-10-13 Contactor 690v

Abb Af09-30-10-13 Contactor 690v
Abb Stotz-Kontakt Gmbh
Af09
Af09-30-10-13
100-250v 50/60hz-Dc
Ui=690v~
Ith=35a
Uimp=6kv
Ie Ac-1=25a
Iec/En 60947-4-1
Gb 14048.4
General Use: 600v Ac 25a
Awg 10-16 Cu 75°C
Torque.13lb.In-1,5nm
Uimp=6kv
Aux,+Coil:
A600 Q600
Awg14-18 Cu 75°C
Torque: 11lb.In-1,2nm
Coil: Uimp=1,5kv
600v Ac Max
B C2-14248
A8791338
11111111111111111
Tf42
Tf42-0.55
1saz721201r1017
0.41-0.55a
Trip Class 10
Iec/En 60947-4-1
Iec/En 60947-5-1
Ue=690v Ac
Ui=690v Ac
Uimp=6kv
Ip20
Scpd
Use 75°C Cu Wire Only
Main Circuit Awg 18-10, Torque 13-22lb.In
Aux Circuit Awg 18-12, Torque 9-11 Lb-In
Db42 Awg 18-5, Torque 13-22 Lb-In
Gb 14048 4/.5
Bvs 13 Atex E 102
Ii (2) G
Ii (2) D
Trip Amps Are 125%Of Fla
2cdc1 6076m6801
D300/Q600
171024 00022
4 013614 398025
Made In France
Made In Germany
Weight : 420 Gm
Ref No : 171586
