Abb Ach580-Bcr-077a-4+E213+F267 Drives Hvac Enclosed Industrial Control Panel 480 V

Abb Ach580-Bcr-077a-4+E213+F267 Drives Hvac Enclosed Industrial Control Panel 480 V
Abb Inc.
Abb Oy Drives
Hvac
Enclosed Industrial Control Panel
Product Type: Vfd
Model Number/Product Name: Ach580
Ach580-Bcr (1…350 Hp, 0.75…250 Kw)
Ach580-Bcr-077a-4+E213+F267
Vfd Rating:
Input: 3ph 50…60hz
Output: 3ph 0…500 Hz
Voltage (U1): 440…480 Vac
Voltage (U2): 0…U1 Vac
Current (I1n)/(I2n): 77a
E-Clipse Package Rating:
Short Circuit: 100 Ka
Power (Pn): 60 Hp
Enclosure Ul Type 1
Orig. Drive Firmware: V2.09.0.0
Orig. Bypass Firmware: V2.020
Schematic
3axd50000313815, 3axd50000312160
No.: F-51179102
E101649
Ach-Ap-H
Code: 3aua0000064886
3aua0000064886d1233611sb
Sw: 5.95
3axd50000223015
Type: Rbcu
3axd50000243624a8400309ws
Rev: A
Id: X-1889866-4
E316774
Rbcu V2
Hcsa-4-1
Code: 3axd50000218653
3axd50000218653b8280519tg
Mov-480v / M0v-480v
Code: 3aua0000008410
3aua0000008410g8170045tg
Base Unit
Cbu-C1-4
Cdpi-01
Code: 3aua0000118614
3aua0000118614c1362983ws
Copi-01 / C0pi-01
3aua0000118152h1362190ws
E243951
Cp 5
94v-0
Cti 3
221350091149(R6990)
10000007806 D 2/2
Ot100f3
1s200b11810501428
3axd50000146406 Rev: A
Emc/Var Kit
Emc/Var Screws
3axd50000561261a
3aua0000114874
Rev: C
Ach580-Bcr-052a-4+B058
3axd50000313839
Ach580-Bdr-03a9-6+B056+E213+J429
Assembled In Mexico
Made In China
Made In Usa
Weight : 87 Kg
Ref No : 171004
