Abb 07kt51-U3.6 Advant Controller 24v

Abb 07kt51-U3.6 Advant Controller 24v
Abb
Advant Controller 31
Basic Unit
07kt51
07kt51-U3.6
1sbp260012r1001
8 24vdc Inputs
6 Transistor Outputs
Power Supply: 24vdc 5w/10w Resp. Without & With Ext
Awg14cu Str60°C
Torque 4.5lbs-Inch (0,5nm)
8 Inputs 0-24vdc 5ma
Awg14-24cu Str60°C
Torque 4.5lbs-Inch (0,5nm)
Output 0 24vdc 1a
Output 1 24vdc 1a
Output 2 24vdc 0,5a
Output 3 24vdc 0,5a
Output 4 24vdc 0,5a
Output 5 24vdc 0,5a
Com 24v Dc 4a
Made In France
Weight : 330 Gm
Ref No : 157816
