HYUNDAI HOR 1K 4.2 THERMAL OVERLOAD RELAY HOR 1K

HYUNDAI HOR 1K 4.2 THERMAL OVERLOAD RELAY HOR 1K



Hyundai Hor 1k 4.2 Thermal Overload Relay Hor 1k
Hyundai Heavy Industries Co., Ltd.
Thermal Overload Relay
Hor 1k 4.2
Hor 1k
Iec 292 Iec 337
Vde0660 Ui=660v~
Bs4941 Ac11 380v
Le=0.5a
Ue=660v~ith=5a
Type C 10a
Type A 25a
Cu Wire 60/75°c
Max Fuse 15a
10a Hrc Form Ii
Trip Rating Is 120% Of Dial Setting
B600
Terminal Torque 12 Lb.in
Above 300v Same Polarity
En 60947-4
Iec 947-4
Part No: Cpae.0501.084
Equipment: Starter Panel
Parts: Thermal Relay, Hor1k,2e, 2,8-4.2a
Parts Code: Hor1k,2e,2.8-4.2a
Made In Korea
Weight : 180 Gm
Condition : New 8 Pcs
Ref No : 30835
