Main Engine
Make : Mitsui Engineering & Ship Building Co. Ltd.-Man B&W
Type : 6S70MC
No. Of Cylinder : 6
Cylinder Bore : 700 MM
Stroke : 2674 MM
Maximum Continuous Output : 14710 Kw (20000 Bhp) At 80 Rpm
Continuous Service Output : 12504 Kw (17000 Bhp) At 75.8 Rpm
Turbocharger
Make : Mitsubishi Heavy Industries Ltd.
Type : MET-83SD
Specification No. : CS3E37DD5N
Rpm : 11000
Temp. : 580 C
Oil Mist Detector
Make : Daihatsu Diesel Mfg. Co. Ltd.
Type : MD-9M
24 VDC : 50 W
Aux Blower
Make : Nishishiba (Nsdk) Electric Co. Ltd.
Type : TBV-59M1
Cap. : 3.44/6.65 M3/Sec.
Stat Pressure : 3200/5600 Pa
Rpm : 3540
Aux Blower Ele. Motor
Make : Mitsubishi Electric Corporation
Type : SF-TV
Kw : 75
Volt : 400-440
Amps : 129-126-117
Rpm : 3540-3560-3570
Hz : 50-60
Aux Blower Ele. Motor
Make : Nishishiba (Nsdk) Electric Co. Ltd.
Type : NTIKK
Kw : 65
Volt : 440
Amps : 103
Rpm : 3540
Hz : 60
Turning Gear
Make : Nara Corporation
Type : NRT-3700M1
Diesel Generators
Make : Daihatsu Diesel Mfg. Co. Ltd.
Type : 6DK-20
No. of. Cylinders : 6
Max. Continuous Rating : 625 Kw
Engine Speed : 720 Rpm
D.G. Governor
Make : Woodward
Type : UG-10D
Part No. : 8527-230/A8526-624TN
Rpm : 730-1520
D.G. Alternator
Make : Taiyo Electric Co. Ltd.
Model : FE547C-10
Kva : 725
Volt : 450
Amps : 930
Rpm : 720
Hz : 60
Emergency Diesel Generators
Make : Man
Type : D2866E
Rating Kw : 132
Rpm : 1800
Emergency Diesel Generator Alternator
Make : Stamford
Type : UC.M274F1
Kva : 200 450
Amps : 257
Rpm : 1800
Hz : 60
Air Compressor
Make : Tanabe Pneumatic Machinery Co. Ltd.
Model : H-273
Cap. : FA 220 M3/Hr.
Pressure : 2.45 MPa
Speed : 1200 Rpm
Power Req. : 40.5 Kw
Air Compressor Ele. Motor
Make : Taiyo Electric Co. Ltd.
Type : TIT225S
Kw : 45
Volt : 440
Amps : 76
Rpm : 1175
Hz : 60
Breathing Air Compressor
Make : Bauer Kompressoren
Type : U-IIE
Volume : 0.100 M3/Min
Free Air De. : 3.5 Scfm
Pressure : 225 Bar
Max. Work. Pressure : 3200 Psig
Rpm : 960
Kw : 2.2
Fresh Water Generator
Make : Sasakura Engineering Co. Ltd.
Type : KE-20
Cap. : 20 Ton/Day
Fresh Water Generator Salinity Indicator Penal
Make : Sasakura Engineering Co. Ltd.
Model : SK-101
Fresh Water Generator Distillate Pump
Make : Teikoku Machinery Works Ltd.
Type : 40 X 3/4MSS
Cap. : 1.2 M3/Hr.
Total Head : 30 M
Speed : 3600 Rpm
Oily Water Separators
Make : Heishin Pump Works Co. Ltd.
Type : HSN-5F
Cap. : 5 M3/H
Max. Work. Press. : 0.3 Mpa
Oily Water Separators Penal
Make : Fellow Kogyo Co. Ltd.
Model : FOCAS-1500C
Fuel Oil Purifier (Oil Filter)
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-40F
Cap. : 5500 L/Hr.
Rpm : 7300
Motor : 7.5 Kw
G.E. Lubricating Oil Purifier (Oil Filter)
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-10F
Cap. : 950 L/Hr.
Rpm : 9000
Motor : 7.5 Kw
Lubricating Oil Purifier (Oil Filter)
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-30F
Cap. : 3100 L/Hr.
Rpm : 9000
Motor : 5.5 Kw
Fuel Refiner Unit
Make : Iris Marine Co. Ltd.,
Type : FR-50
Oil Strainer
Make : Kanagawa Kiki Kogyo Co. Ltd.
Type : K8E8SZ-W30LE-X
Cap. : 360 M3/Hr.
Filter Limit : 50 L.
Unit Attach Chilling Compressor
Make : Daikin Ind. Ltd.
Model : JT300D-YE@N
Refr. : R-22
Dp/AP : H-3.0 MPa L-1.3 MPa
Sp : H-9.0 MPa L-3.9 MPa
Small Chilling Compressor
Make : Daikin Ind. Ltd.
Model : JT160B-NFYE@K
Refr. : R-22
Dp/AP : H-2.8 MPa L-1.3 MPa
Sp : H-8.4 MPa L-3.9 MPa
Small Chilling Compressor
Make : Daikin Ind. Ltd.
Model : JT160B-NFYE
Refr. : R-22
Dp/AP : H-2.8 MPa L-1.3 MPa
Sp : H-8.4 MPa L-3.9 MPa
Air Condition Unit
Make : Daikin Ind. Ltd.
Model : US5GE
Ref. : R-22
Output Comp. : 3.75 Kw
Fan : 0.4 Kw
Design Pressure High-Low : 2.5/1.3 Mpa
Plate Heat Exchanger
Make : Alfa Laval
type : M6-MFM
Plate Heat Exchanger
Make : Alfa Laval
Type : M10-MFM
Plate Heat Exchanger
Make : Alfa Laval
Type : M20-MFM
Over Head Crane (Engine Room)
Make : Sekigahara Seisakusho Ltd.
Type : MB-5
Cap. : SWL 5 Ton
Steering Room’s Hydraulic Pump
Make : Fukushima Ltd.
type : FG12-A
Rpm : 415
Nominal Pressure : 3.9 Mpa
Safety Valve Set Pressure : 4.4 Mpa
Hydraulic Pump Attach Speed Reducer Pump
Make : Fukushima Ltd.
Type : CA-4.2F2
Ratio : 1:4.22
Steering Room’s Hydraulic Pump
Make : Fukushima Ltd.
Type : FG16-A
Rpm : 300
Nominal Pressure : 3.9 Mpa
Safety Valve Set Pressure : 4.4 Mpa
Hydraulic Pump Attach Speed Reducer Pump
Make : Fukushima Ltd.
Type : CA-5.8F2
Ratio : 1:5.83
Hydraulic Power Pack Unit
Make : Nakakita-Seisakusho Co. Ltd.,
Pump Max. Pressure : 9.8 Mpa
Pump Disch. Cap. : 6.5 L/Min.
Ele. Motor : 1.5 Kw
Oil Tank Cap. : 25 Liter
Hydraulic Pump Unit’s Pump
Make : Yuken Kogyo Co. Ltd.
Model : AR16-FR01C-20
Max. Pressure : 16 Mpa
Max. Disp. : 15.8 Cm3/Rev.
Hydraulic Power Pack Unit
Make : Macgregor
Displacement : 13×2=26 L/Min.
Relief Pressure : 21 Mpa
Driving Motor : Kw-5.5 Rpm-1730
Tank Cap. : 465 Liert
Hydraulic Pump Unit’s Pump
Make : Rexroth
Type : A10VSO-18-DFR1/31R-PPA12N00
Elevator Machine
Make : Schindler Elevator K.K.
Type : 750
Motor Cap. : 3.7 Kw
Sheave Dia. : 520 MM
Rated Speed : 30 M/Min
Gear Ratio : 1/63
Boiler Feed Water Pump
Make : Shinko
Type : SHQ-50MU
Cap. : 4 M3/Hr.
Total Head : 100 M
Central Cooling Sea Water Pump
Make : Shinko
Type : SVA-250MU
Cap. : 460 M3/Hr.
Total Head : 20 M
Sea Water Pump
Make : Shinko
Type : SVA-150MU
Cap. : 160 M3/Hr.
Total Head : 20 M
Ballast Pump
Make : Shinko
Type : RVD-500MU
Cap. : 2800 M3/Hr.
Total Head : 30 M
Jacket Cooling Fresh Water Pump
Make : Shinko
Type : SVA-125MU
Cap. : 121 M3/Hr.
Total Head : 32 M
Fire & Bilge Pump
Make : Shinko
Type : RVP-250MUS
Cap. : 90-400 M3/Hr.,
Total Head : 35-75 M
Fire & General Service Pump
Make : Shinko
Type : RVP-250MUS
Cap. : 90-400 M3/Hr.
Total Head : 35-75 M
Camshaft L.O. Booster Pump
Make : Taiko Kikai Ind. Ltd.
Type : NHG-10MT
Cap. : 10 M3/Hr.
Rpm : 1200
Power : 2.2 Kw
Emergency Fire Pump
Make : Shinko
Type : RVP-130MUS
Cap. : 72 M3/Hr.
Total Head : 75 M
Emergency Fire Pump’s Ele. Motor
Make : Taiyo Electric Co. Ltd.
Type : TDV180S
Kw : 30
Volt : 440
Amps : 50
Rpm : 1745
Hz : 60
Sludge Pump
Make : Taiko Kikai Ind. Ltd.
Type : HNP-401
Cap. : 4 M3/Hr.
Rpm : 280
Power : 2.2 Kw
Sludge Pump
Make : Taiko Kikai Ind. Ltd.
Type : HNP-401
Cap. : 2 M3/Hr.
