Main Engine
Make : General Electric
Engine Model : 7FDM-16D12
No. of. Cylinders: 16
Rated Speed: 1000 Rpm
Rated Power: 3910 Hp
Main Engine Attach Gearbox (With Fire Fighting Pump)
Make : Kumera-Norgear Marine Transmission
Type : FVIC-250-75F
Kw : 716
Ratio : 1:1.8
Rpm : 1000
Gearbox Attach Fire Fighting Pump
Make : ABS Production Vadstena Ab
Type : SFP 250x3500D CW
Cap. : 1595 M3/Hr.
Rpm : 1800
Head : 20 M
Diesel Generator
Make : Caterpillar
Engine Model : C-18
Power : 624 Bhp (465 BkW) At 1500 Rpm
D.G. Alternator
Make : Caterpillar
Engine Model : C-18
Kva : 531
Kw : 425
Volt : 440
Amps : 697
Rpm : 1800
Hz : 60
Emergency Diesel Generators
Make : Caterpillar
Engine Model : C-4.4 DITA
Power : 122 Hp (92-Kw) At 1800 Rpm
Emergency Diesel Generator Alternator
Make : Leroy Somer
Type : LSAM44.2VS3C6/4
Kva : 93.6-94.3-94.9
Kw : 74.9-75.4-75.9
Volt : 220-240-298-380-440-480
Amps : 114-124-141-226-247-261
Rpm : 1800
Hz : 60
Lubricating Oil Purifiers (Oil Filter)
Make : Alfa Laval
Type : P-605
Max. Speed (Bowl) : 9307 Rpm
Speed Motor Shaft : 9307 Rpm
Motor Power : Kw-2.5 Hz-60
Fuel Oil (Oil Filter)
Make : Alfa Laval
Type : P-615
Max. Speed (Bowl) : 9307 Rpm
Speed Motor Shaft : 3600 Rpm
Motor Power : Kw-3.7 Hz-60
Fuel Oil & Lubricating Oil (Oil Filter) EPC Peanl
Make : Alfa Laval
Type : EPC-50
Moatti Oil Filter
Make : Alfa Laval Moatti Sas
Type : T-280 20A03
Max. Working Pressure : 12 Bar
Max. Working Temp. : 100 C
Air Compressor
Make : Sperre
Type : HL2/90
Cap. : 38 M3/Hr.
Pressure : 30 Barg
Power : 10.2 Kw
Speed : 1750 Rpm
Air Compressor Ele. Motor
Make : Abb
Type : M3AA-132 MB-4
Kw : 9.5-11
Rpm : 1450-1750
Amps : 11-19
Volt : 380-420-660-690-440-480
Hz : 50-60
Screw Air Compressor
Make : Neuenhauser Kompressorenbau Gmbh
Type : 282202011021
F.A.D. : 24 M3/Hr.
Operating Pressure : 30 Bar
Speed : 1500 Rpm
Power : 6.2 Kw
Oily Water Separators
Make : Taiko Kikai Ind. Co. Ltd.
Model : USH-10
Cap. : 1 M3/Hr.
Max. Working Pressure : 0.2 Mpa
Oily Water Separator Penal
Make : Fellow Kogyo Co. Ltd.
Model : FOCAS-1800
Chilling Compressor
Make : Carlyle
Model : 06EA275600
Chilling Compressor
Make : Carlyle
Model : 06EA575600
Small Chilling Compressor
Make : Bitzer
Type : IV
Cap. : 7.3-14.9 M3/Hr.
Rpm : 370-750
Pressure : 19-23 Bar
Small Chilling Compressor
Make : Bitzer
Type : IVY
Cap. : 7.3-14.9 M3/Hr.
Rpm : 370-750
Pressure : 19-23 Bar
Air Condition Unit
Make : Paramount Airtech Pte Ltd.
Model : PA/RP 4W5
Plate Heat Exchanger
Make : Alfa Laval
Type : A10-MFM
Steering Gear
Make : Schottel
Type : SRP-3030-GP
Steering Gear Attach Hydraulic Pump
Make : Linde
Type : HPV210-02-OV-0000
Steering Gear Attach Slewing Gear
Make : Brevini Power Transmission
Type/Model : ED2250
Slewing Gear Attach Hydraulic Pump
Make : Linde
Type : HMF105-02-2600
Hydraulic Power Pack’s Pump
Make : Eaton Fluid Power Ltd.
Model : PVH131R-16AF30E-252004001-AD1AA010A
Hydraulic Power Pack Attach Hydraulic Pump
Make : Parker
Type : PV180R1K1T1NFFP
Deck Provisions Hydraulic Crane
Make : Palfiner Systems
Type : PTM330AS4.5S
Main Engine Lub. Oil Pump
Make : Azcue
Type : BT-IL 52D3
Cap. : 11 M3/Hr.,
Head : 100 M,
T.P. : Bar
AC & Refr. Sea Water Cooling Pump
Make : Azcue
Type : MN65-250
Cap. : 60 M3/Hr.
Head : 28 M
T.P. : Bar
General Service & Bilge Pump
Make : Azcue
Type : CA80/10-A
Cap. : 45 M3/Hr.
Head : 50 M
T.P. : 8 Bar
Bilge Pump
Make : Azcue
Type : CA80/15-A
Cap. : 10 M3/Hr.
Head : 50 M
T.P. : 8 Bar
Water Pump
Make : Azcue
Type : CA80/15-A
Cap. : 70 M3/Hr.
Head : 50 M
T.P. : 8 Bar
Main Engine Sea Water Cooling Pump
Make : Azcue
Type : VM100-33A
Cap. : 150 M3/Hr.
Head : 30 M
T.P. : 6 Bar
Sewage Water Pump
Make : Azcue
Type : CA50/4
Cap. : 10 M3/Hr.
Head : 30 M
T.P. : 6 Bar
F.O. Cargo Pump
Make : Azcue
Type : BT-LV 125TZ
Cap. : 100 M3/Hr.
Head : 50 M
T.P. : 12 Bar
Recovery Oil Pump
Make : Azcue
Type : CA80-10A
Cap. : 70 M3/Hr.
Head : 50 M
Emergency Fire Pump
Make : Azcue
Type : CA50-7A
Cap. : 25 M3/Hr.
Head : 45 M
T.P. : 8 Bar
Hydraulic Deck Windlass Anchor Winch Attach Hydraulic Motor
Make : Hagglunds
Type : CA 210 210 SALN00 02 00
Max. Pressure : 350 Bar
Hydraulic Towing Winch
Make : Plimsoll
Model : AHTW/WF-150/250
Rating : DRUM CAP. 1000 M X 64 MM SWR @ 9 Layers
Rated Pull (1St Layer) : 150 Ton X 0~6 M/Min. (1St Speed),
75 Ton X 0~12 M/Min. (2nd Speed)
25 Ton X 0~36 M/Min. (3rd Speed)
DYNAMIC LOWERING (1st Layer) : 150 Ton-0~12 M/Min.
250 Ton (Static 1st Layer) Brake Hold,
Hydraulic Towing Winch’s Hydraulic Motor
Make : Hagglunds
Type : CA 210 210 SALN00 02 00
Hydraulic Towing Winch’s Hydraulic Motor
Make : Hagglunds
Type : CA 50 50 SA0N00 02 00
