Main Engine
Make : Akasaka Diesel Ltd.-Mitsubishi Ue Diesel Engine
Type : 6UET45-75C
No. of. Cylinders : 6
Ps : 3800
Rpm : 230
Governor
Make : Woodward
Type : UG-8
Diesel Generators (With Gearbox)
Make : Daihatsu Diesel Mfg. Co. Ltd.
Type : 6PKT-16
No. of. Cylinders : 6
Cylinder Bore : 160 MM Stroke : 210 MM
Maximum Continuous Rating : 270 Ps
Engine Speed : 1200 Rpm
D.G. Alternator
Make : Nishishiba (Nsdk) Electric Co. Ltd.
Type : NTAKC
Kva : 200
Hz : 60
Volt : 445
Rpm : 1200
Diesel Generator (With Gearbox)
Make : Yanmar Diesel Engine Co. Ltd.
Model : S165L-ST
No. of. Cylinders : 6
Continuous Rating : 420 Ps
Speed Of Crankshaft : 900 Rpm
D.G. Alternator
Make : Taiyo Electric Co. Ltd.
Model : FE38C-8
Kva : 350
Hz : 60
Volt : 450
Rpm : 900
Amps : 449
Canopy Type Emergency Diesel Generator Set
Make : Nippon Sharyo Seizo Kaisha Ltd.
Model : NES-90SN
Engine : NE-605
Engine Output : Ps-95/113 Hz-50/60
Alternator : NEA-7504
Alternator Output : Kva-75/90 Volt-200/400
Amps-109/217
Engine
Make : Nippon Diesel Motor Co. Ltd.
Model : NE-6
Type : O5
Ps : 95/115 Ps
Rpm : 1500/1800
Alternator
Make : Nippon Sharyo Ltd.
Model : NEA-7504
Kva : 75/90
Volt : 200/400
Amps : 109/217
Emergency Diesel Generator
Make : Caterpillar, Engine
Model : 3304
Emergency D.G. Alternator
Make : Caterpillar
Model : 3304
Kva : 81
Kw : 65
Rpm : 1800
Amps : 107
Volt : 440
Hz : 60
Emergency Diesel Generator
Make : Yanmar Diesel Engine Co. Ltd.
Model : S165L-ST
No. of. Cylinders : 6
Continuous Rating : 540 Ps
Speed Of Crankshaft : 1200 Rpm
Engine No. : 0270-FJS
Emergency D.G. Alternator
Make : Fuji Electric Co. Ltd.
Type : GFV-4404E-6
Kva : 437.5
Hz : 60
Volt : 450
Rpm : 1200
Amps : 561
Air Compressor
Make : Matsubara Iron Works Ltd.
Type : MS-92A
Air Compressor
Make : Atlas Copco
Type : LT20-30UW BM
Max. Pressure : 30 Bar
Cap. : 17 L/Sec.
Power : Kw-13.5
Volt-400
Hz-50
Rpm-1500
Air Compressor Ele. Motor
Make : Leroy Somer
Type : LS160-LR
Kw : 15/18
Hz : 50/60
Volt : 400/460
Rpm : 1450/1740
Amps : 28.9/29
Air Compressor (With Tank)
Make : Fini Compressor
Type/Model : BK-119
Air Compressor Ele. Motor
Make : FSN
Type : 112L-2B3
Kw : 5.5/6.6
Hz : 50/60
Volt : 380/800
Rpm : 2880/3450
Amps : 12.6/88
Fresh Water Generators
Make : Sasakura Engineering Co. Ltd.,
Type : AFGU No.3
Cap. : 10 Ton/Day
Fresh Water Generators Salinity Indicator Penal
Make : Sasakura Engineering Co. Ltd.
Type : S5-601
Oily Water Separators
Make : Victor Marine Ltd.
Type : CS-2000
Cap. : 2 M3/Hr.
Max. Working Pressure : 3.45 Ba
Oily Water Separators Penal
Make : Rivertrace Engineering,
Type/Model : SMART-CELL BILGE
L.O. Purifiers (Oil Filter) Purifiers
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-2000 (01 Pcs)
Cap. : 2000 L/Hr.
Rpm : 8000
Kw : 3.7
H.F.O. Purifiers (Oil Filter) Purifiers
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-2000
Cap. : 2000 L/Hr.,
Rpm : 8000
Kw : 3.7
Water Pump (With Engine)
Make : Abdul Zahir Bashir General Tradring Llc
Model : KDP-30M
Con. Cap. : 28 M3/Hr.
Cont. Head : 12 M
Pump Speed : 3600 Rpm
Max. Suction Head : 8 M
Suction/Disch. Port Dia. : 80(3″) MM
Water Pump Attach Engine
Make : Covax
Model : KM170F
Rated Power : 2.5/2.8 Kw
Rated Speed : 3000/3600 Rpm
Total Displacement of Piston (L) : 0.211
Water Pump (With Engine)
Make : Koshin Ltd.,
Model : SEY-80D
Type : BAA-0
Cont. Cap. : 880 L/Min.-232 Gla/Min.
Total Cont. Head : 26 M
Pump Speed : 3600 Rpm
Suction/Disch. Port Dia. : 80(3″) MM
Water Pump Attach Engine
Make : Yanmar
Model : L48N6-RKSYI
Max. Output : Kw-3.5 Rpm-3600
Displacement : 0.219 L
Over Head Crane (Engine Room)
Make : Hitachi Ltd.
Cap. : SWL 2 Ton
Steering Gear
Make : Kawasaki Heavy Industries Co. Ltd.,
Type : R-170ATO
Steering Room’s Hydraulic Pump
Make : Uchida Hydromatik
Model : A7V160LV1RPF 00-J
Steering Room’s Hydraulic Pump
Make : Uchida Hydromatik
Model : A2V225LV0RIG 00PF00015-J
