Main Engine
Make : Hyundai Heavy Industries Co. Ltd.-Man B&W
Type : 6S35MC
No. of. Cylinders : 6
Cylinder Bore : 350 MM x Stroke 1400 MM
Maximum Continuous Output : 5700 Bhp At 170 Rpm
Continuous Service Output : 5130 Bhp At 164.1 Rpm
Turbocharger
Make : ABB
Type : VTR-354-32
Oil Mist Detector
Make : Visatron (Schaller Automation)
Type : VN 215/87 PLUS
Art No. : 11851
Turning Gear
Make : Kyung In Heavy Industries
Model : KI-350
Ratio : 1701.8
Diesel Generator
Make : Yanmar Diesel Engine Co. Ltd.
Model : M220AL-UN
No. of. Cylinders : 6
Continuous Rating : 1000 Ps
Speed Of Crankshaft : 900 Rpm
D.G. Governor
Make : Zexel
Type : RHD6-MC
Part No. : 105856-5440
Rpm : 600-2000
Diesel Generator Alternator
Make : Hyundai Heavy Industries Co. Ltd.
Type : HFC6-506-08P
Kw : 895
Volt : 450
Amps : 1148.5
Rpm : 900
Hz : 60
Emergency Diesel Generator Alternator
Make : Stamford
Type : UCM274C1
Kva : 80
Kw : 64
Rpm : 1800
Volt : 450
Amps : 102.6
Hz : 60
Main Engine & G.E. Lubricating Oil Purifiers (Oil Filter)
Make : Westfalia Separator
Type : OSC4-02-066
Rpm : 10030
Diesel & Fuel Oil Purifiers (Oil Filter)
Make : Westfalia Separator
Type : OSA7-02-066
Rpm : 8510
Air Compressor
Make : Matsubara Iron Works Ltd.
Model : MH-114A
Press. : 2.94 Mpa
Revol. : 1200 Rpm
Piston Displacement : 101.0 M3/Hr.
Power Req. : 17.4 Kw
Emergency Air Compressor
Make : Sanwa Co. Ltd.
Model : 3S10A
Pressure : 2.45 Mpa
Speed : 1300 Rpm
Displacement : 42.9 M3/Hr.
Cap. : 32.5 M3/Hr.,
Emergency Air Compressor Ele. Motor
Make : Hitachi Ind. Equip. Systems Co. Ltd.
Type : TFO
Kw : 7.5
Volt : 440
Hz : 60
Rpm : 1160
Amps : 14
Mass : 75 Kg
Screw Air Compressor
Make : Tamrotor
Type : M200-10EWA
Cap. : 30 M3/Hr.
Max. Pressure : 1056
Rpm : 265
Power : Kw-230 Volt-440 Hz-60
Gas Cargo Compressor
Make : Sulzer Burckhardt
Type : 2K 160-2F
Gas : LPG/NH3/VCM
Speed : 590 Rpm
Gas Cargo Compressor’s Ele. Motor
Make : NEC
type : HM-56
Kw : 530
Volt : 440
Rpm : 592
Amps : 607
Hz : 60
Gas Cargo Compressor
Make : Howden Compressors Ltd.
Hydraulic Test Pressure : 42.00 Barg
Max. Working Pressure High Side/Low Side : 18.00/2.00 Barg
Max. Speed : 3600 Rpm
Contract No. : Y02186 R25201-1E
Gas Cargo Compressor’s Ele. Motor
Make : ATB
Type : FM-45
Kw : 350
Volt : 440
Rpm : 3576
Amps : 532
Hz : 60
Air Compressor (With Tank) Ele. Motor
Make : Higen Motor Co. Ltd.
Type : KMH-15HV1
Kw : 11
Hp : 15
Volt : 440
Rpm : 1760
Amps : 19.5
Hz : 60
Fresh Water Generator
Make : Alfa Laval
Type : JWP-26-C80
Cap. : 10 M3/Hr.
Oily Water Separator
Make : Sasakura Engineering Co. Ltd.
type : SMT-3A
Cap. : 3 M3/Hr.
Oily Water Separators OMD
Make : Fellow Kogyo Co. Ltd
Model : FOCAS-1500C
Small Chilling Compressor
Make : Bitzer
Type : IV
Chilling Compressor
Make : Copeland Discus
Model : 4DBNR20ME-TSK-C00
Volt : 200/208/230/380/400/480
Hz : 50/60
Air Condition Unit
Make : Daikin Ind. Ltd.
Model : USN8HB
Output Comp. : 5.5 Kw
Fan : 0.75 Kw
Design Pressure High-Low : 2.78/2.0 Mpa
Plate Heat Exchanger
Make : Alfa Laval
Type : M6-MFG
Plate Heat Exchanger
Make : Dong Hwa Precision Ind. Co. Ltd.,
Type : S30-IS
Steering Gear
Make : Yoowon Ind. Co. Ltd.
Type : YSFC-3G-2
Pump : T60-996
Max. Torque : 25 Tm
Safety Valve Pressure : 219 Kg/Cm2
Hydraulic Power Pack
Make : Aquamaster Rauma
Type : HP3-2/57-CP
Design Pressure : 250 Bar
Hydraulic Windlass Anchor Winch
Make : Rolls-Royce Deck Machinery-Brattvag
Type : CU46U3
