Main Engine
Make : Kawasaki Heavy Industries Ltd.-Man B&W
Type : 8S60MC
No. of. Cylinders : 8
Output Ps : 18327
Output Kw : 13480
Engine Speed : 105 Rpm
Engine No. : 7837
Turbocharger
Make : Kawasaki Heavy Industries Ltd.-Man B&W
Type : NA48/S01079
Max. Speed : 17800 Rpm
Max. Gas Temp. : 620 C
Oil Mist Detector
Make : Daihatsu Diesel Mfg. Co. Ltd.
Type : MD-9M
Volt : DC 24
Current : 2.0 A
Aux Blower
Make : Taiyo Electric Co. Ltd.
Model : TB-62W
Volume : 3.33-6.40 M3/Sec.
Pressure : 5.6-3.2 kPa
Rpm : 3530
Aux Blower Ele. Motor
Make : Taiyo Electric Co. Ltd.
Type : TF-250S-2
Kw : 75
Volt : 440
Amps : 116
Rpm : 3530
Hz : 60
Air Cooler
Make : Gea
Type : 4KFD4-1
Turning Gear
Make : Cyclo-Sumitomo Heavy Ind. Ltd.
Model : CHHMS5-4215DB-B-1849
Ratio : 1849
Torque : 1600-3200 Kgf-m
Diesel Generator
Make : Daihatsu Diesel Mfg. Co. Ltd.
Type : 8DK-20
No. of. Cylinders : 8
Maximum Continuous Rating : 1020 Kw (Ps : 1387)
Engine Speed : 720 Rpm
D.G. Turbocharger
Make : IHI
Type : RH-183
D.G. Governor
Make : Zexel
Type : RHD6-MC
Part No. : 105856-5351
Rpm : 600-2000
D.G. Alternator
Make : Taiyo Electric Co. Ltd.
Model : FEK50B-10
Kva : 1200
Volt : 450
Amps : 1540
Rpm : 720
Hz : 60
Emergency Diesel Generators
Make : Deutz
Type : BF6L913
Kw : 105.5
Rpm : 1800
Emergency Diesel Generator Alternator
Make : Stamford
Type : UC.M274F1
Kva : 120
Volt : 450
Amps : 154
Rpm : 1800
Hz : 60
Air Compressor
Make : Tanabe Pneumatic Machinery Co. Ltd.
Model : H-74
Vertical Type Two-Stage Water Cooled
Bore L.P. 180 X H.P. 140 X Stroke 80
Pressure : 2.94 Mpa
Cap. : F.A. 200 M3/Hr.
Speed : 1800 Rpm
Power Re. : 44.1 Kw
Air Compressor Ele. Motor
Make : Taiyo Electric Co. Ltd.
Type : TIT-225S
Kw : 50
Volt : 440
Amps : 83
Rpm : 1765
Hz : 60
Air Compressor Ele. Motor
Make : Mitsubishi Electric Corporation
Type : SF-JK
Kw : 55
Volt : 440
Amps : 89
Rpm : 1770
Hz : 60
Generator Engine Lubricating Oil Purifiers (Oil Filter)
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-10F
Cap. : 950 Liter/Hr.
Rpm : 9000
Motor : 5.5 Kw
Main Engine Lubricating Oil Purifiers (Oil Filter)
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-30F
Cap. : 3100 Liter/Hr.
Rpm : 9000
Motor : 5.5 Kw
Heavy Fuel Oil Purifiers (Oil Filter)
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-40F
Cap. : 5500 Liter/Hr.
Rpm : 7300
Motor : 7.5 Kw
Fresh Water Generator
Make : Sasakura Engineering Co. Ltd.
Type : KM-20
Cap. : 20 Ton/Day
Fresh Water Generator Salinometer
Make : Sasakura Engineering Co. Ltd.
Model : SK-101
Fresh Water Generator Distillate Pump
Make : Teikoku.
Type : 40×8/4″ MSS
Oily Water Separators
Make : Oily Water Separators
Make : Heishin Pump Works Co. Ltd.
Type : HMS-200
Cap. : 2 M3/Hr.
Test Pressure : 0.2 Mpa
O.W.S. Bilge Monitor Penal
Make : Fellow Kogyo Co. Ltd.
Model : FOCAS-1500C
Chilling Compressor
Make : Mitsubishi Ele. Corp.
Model : MR-6MS
Refr. : R-22
Dp : H-2.5 Mpa L-1.3 Mpa
Dt : H-150.20 Mpa L-40–35 C
Tp : H-4.0 Mpa L-2.1 Mpa
Ap : H-2.7 Mpa L-1.5 Mpa
Power : Volt-440/110 Hz-60
Small Chilling Compressor
Make : Mitsubishi Ele. Corp.
Model : FA-2LSYM2
Refr. : R-22
L.R.A. : 44-46-48
A.P. : (H) 2.8 Mpa (L) 1.4 Mpa T.P. : (H) 4.6 Mpa (L) 2.1 Mpa D.P. : (H) 2.8 Mpa (L) 1.4 Mpa
D.P : Max (H) 2.8 Mpa Min. (L) : -45 C
Volt : 380-415-440-460
Hz : 60
Small Chilling Compressor
Make : Mitsubishi Ele. Corp.
Model : FA-2LSY
Refr. : R-22
L.R.A. : 44-46-48
A.P. : (H) 28 Kg/Cm2 (L) 14 Kg/Cm2
T.P. : (H) 46 Kg/Cm2 (L) 21 Kg/Cm2
D.P. : (H) 28 Kg/Cm2 (L) 14 Kg/Cm2
D.P : Max (H) 150 C Min. (L) : -45 C
Volt : 380-415-440-460
Hz : 60
Small Chilling Compressor
Make : Daikin Ind. Ltd.
Model : 2C582SE-F
Refr. : R12-R22
Rpm : 600
Dp/Ap : (H) 2.2-2.2 Mpa (L) 1.5-1.5 Mpa
Tp : (H) 3.3 Mpa (L) 2.3 Mpa
Air Condition Unit
Make : Daikin Ind. Ltd.
Model : USP5HR1
Refr. : R404A 3.5 Kg
Comp. : 3.75 Kw
Fan : 0.4 Kw
Power : Volt-380-440 Hz-50/60
Candle Filter
Make : Misuzu Machineries & Engine Ltd.
Type : 6.44.07 GR25 MD300
Flow Rate : 350 M3/Hr.
Plate Heat Exchanger
Make : Alfa Laval
Type : M15-BFM8
Plate Heat Exchanger
Make : Hisaka Works Ltd.
Type : RX-136B-NHJM-25
Steering Gear
Make : Kawasaki Heavy Industries Ltd.
Type : FM21-207
Max. Safety Valve Set Pressure : 29.4 Mpa
Max. Working Pressure : 23.5 Mpa
Torque : 2030 kNm
Hydraulic Power Pack’s Hydraulic Pump
Make : Daikin Ind. Ltd.
Model No. : V15A 2R-95
Hydraulic Power Pack Unit
Make : Kawasaki Heavy Industries Ltd.
Item : 30 Pump Unit
Hyd. Pump : K3VG180
Pressure : 18.9 Mpa
Rpm : 250
Fire-Bilge & Ballast Pump
Make : Heishin Pump Works Co.,
Type : VSK-150L
Cap. : 200 M3/Hr.
Del. Bore : 200 MM
Total Head : 0.25-0.74 Mpa
Rpm : 1760
Power : 46 Kw
Fire & Bilge Pump
Make : Heishin Pump Works Co.,
Type : VSK-250L
Cap. : 100-400 M3/Hr.
Del. Bore : 250 MM
Total Head : 0.25-0.74 Mpa
Rpm : 1760
Power : 75 Kw
Drinking Water Pump
Make : Heishin Pump Works Co.
Type : UHY-15L
Cap. : 5 M3/Hr.
Del. Bore : 5 MM
Total Head : 0.59 Mpa
Rpm : 3440
Power : 5.5 Kw
Sludge Pump
Make : Heishin Pump Works Co.
Type : NE-40PM
Cap. : 5 M3/Hr.
Del. Bore : 65 MM
Total Head : 4.0 M
Rpm : 665
Power : 2.2 Kw
Bilge Pump
Make : Heishin Pump Works Co.
Type : HP-2A
Hydraulic Ramp Door Winch
Make : Shinwa Giken Co. Ltd.
Type : D43-249
Rated : 8 Ton 16 M/Min
