Main Engine
Make : Kobe Diesel Co. Ltd.-Mitsubishi Ue Diesel Engine
Type : 8UEC-60LS-II
No. of. Cylinders : 8
Kw : 13940
Rpm : 99
Engine No. : UE-2488
Turbocharger
Make Mitsubishi Heavy Industries Ltd.
Type : MET-66SC
Specification No. : DA2G40ED5N
Rpm : 14800
Temp. : 580 C
Oil Mist Detector
Make Daihatsu Diesel Mfg. Co. Ltd.
Type : MD-9M
Volt : DC 24 V
Current : 2.0 A
Aux Blower Ele. Motor
Make : Abb
Type : M3AA 180-LB2
Kw : 55
Volt : 440
Amos : 55
Rpm : 3540
Hz : 60
Turning Gear
Make : Seisa Gear Drive Ltd.
Type : DTN-1450A
Ratio : 1091.37
Diesel Generator
Make : Daihatsu Diesel Mfg. Co. Ltd.
Type : 5DK-26
No. of. Cylinders : 5
Maximum Continuous Rating : 1280 Kw
Engine Speed : 720 Rpm
Engine No. : DK526Z0026/DK526Z0027/DK526Z0028
D.G. Turbocharger
Make : ABB,
Type : TPS-52D01
D.G. Governor
Make : Zexel,
Type : RHDIO-MC
Part No. : 105866-5260
Rpm : 600-2000
D.G. Alternator
Make : Nishishiba (Ndsk) Electric Co. Ltd.
Type : NTAKL
Kva : 1500
Volt : 450
Amps : 1925
Rpm : 720
Hz : 60
Emergency D.G.
Make : Deutz Diesel Engine Co. Ltd.
Type : BF6L913C
Kw : 137
Rpm : 1800
Emergency Diesel Generator Alternator
Make : Nishishiba (Ndsk) Electric Co. Ltd.
Type : NTAKL
Kva : 150
Volt : 450
Amps : 192.5
Rpm : 1800
Hz : 60
Air Compressor
Make : Tanabe Pneumatic Machinery Co. Ltd.
Model : H-264
Pressure : 2.45 MPa
Cap. : FA 250 M3/Hr.
Speed : 1800 RpM
Power Req. : 51.9 Kw
Air Compressor Ele. Motor
Make : Nishishiba (Ndsk) Electric Co. Ltd.
Type : NTIKK
Kw : 55
Volt : 440
Amps : 88
Rpm : 1755
Hz : 60
Emergency Air Compressor
Make : Matsubara Iron Works Ltd.
Model : MG90-A
Pressure : 2.45 Mpa
Rpm : 1150
Cap. : 32.5 M3/Hr.
Power Req. : 5.5 Kw
Emergency Air Compressor Ele. Motor
Make : Nishishiba (Ndsk) Electric Co. Ltd.
Type : NTIKK
Kw : 5.5
Volt : 440
Amps : 10.4
Rpm : 1150
Hz : 60
Heavy Fuel Oil Purifiers (Oil Filter)
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-40FH
Cap. : 5500 Liter/Hr
Rpm : 7300
Motor : 7.5 Kw
Lubricating Oil Purifiers (Oil Filter)
Make : Mitsubishi Kakoki Kaisha Ltd.
Model : SJ-40F
Cap. : 5500 Liter/Hr.
Rpm : 7300
Motor : 7.5 Kw
Fresh Water Generator
Make : Sasakura Engineering Co. Ltd.
Type : KE-20
Cap. : 20 Ton/Day
Fresh Water Generator Salinometer
Make : Sasakura Engineering Co. Ltd.
Model : SK-101
Fresh Water Generator Distillate Pump
Make : Tekoku Machinery Works-Sasakura Engineering Co. Ltd.,
Type : 40×3/4MSS
Cap. : 2 M3/Hr.
Total Head : 30 M
Speed : 3600 Rpm
Fresh Water Generator Ejector Pump
Make : Tekoku Machinery Works-Sasakura Engineering Co. Ltd.
Type : 100NTSm
Cap. : 42 M3/Hr.
Total Head : 48 MM
Rpm : 3500
Oily Water Separators
Make : Heishin Pump Works Co. Ltd.
Type : HFM-200
Cap. : 2 M3/Hr.
Max. Working Pressure : 0.3 Mpa
Oily Water Separators OMD Penal
Make : Brannstrom Sweden
Type/Model : BilgMon-488
Small Chilling Compressor
Make : Mitsubishi Ele. Corp.
Model : FA-2LSYM2 (02 Pcs)
Refr. : R-22
L.R.A. : 44-46-48
A.P. : (H) 2.8 Mpa (L) 1.4 Mpa T.P. : (H) 4.6 Mpa (L) 2.1 Mpa D.P. : (H) 2.8 Mpa (L) 1.4 Mpa
D.P : Max (H) 2.8 Mpa Min. (L) : -45 C
Volt : 380-415-440-460
Hz : 60
Small Chilling Compressor
Make : Daikin
Model : 2C582LE-CF
Refr. : R12-R22
Rpm : 700
Dp/Ap : (H) 2.2-2.2 Mpa (L) 1.5-1.5 Mpa
Tp : (H) 3.3 Mpa (L) 2.3 Mpa
Chilling Compressor
Make : Mitsubishi Ele. Corp.
Model : MR-6MS
Refr. : R-22
Dp : H-2.5 Mpa L-1.3 Mpa
Dt : H-150.20 Mpa L-40–35 C
Tp : H-4.0 Mpa L-2.1 Mpa
Ap : H-2.7 Mpa L-1.5 Mpa
Power : Volt-440/110 Hz-60
Air Condition Unit
Make : Ushio Reinetsu Co. Ltd.
Model : UAP-3HF4PN
Refr. : R-22 2.5 Kg
Comp. : 3.7 Kw
Fan : 0.75 Kw
Power : Volt-440 Hz-50/60
Plate Heat Exchanger
Make : Hisaka Works Ltd.
Type : UX-196B-NHJM-29
Mass (Empty) : 280 Kg
Plate Heat Exchanger
Make : Hisaka Works Ltd.
Type : RX-795-N-M-181
Plate Heat Exchanger
Make : Hisaka Works Ltd.
Type : UX-995-NPM-203
Over Head Crane (Engine Room)
Make : Sekigahara Seisakusho Ltd.
Type : ML-2B
Cap. : SWL 3 T
Candle Filter
Make : Boll & Kirch Filterbau Gmbh
Type : 6.44 DN 250 GR 25
Candle Filter
Make : Boll & Kirch Filterbau Gmbh
Type : 6.61.DN.100
Steering Gear
Make : Mitsubishi Heavy Industries Ltd.
Type : DF-170
Safety Valve Pressure : 270 Mpa
Steering Gear’s Hydraulic Pump
Make : Mitsubishi Heavy Industries Ltd.-Janney Pump
Type : 1V-FH2B-MK-RFBLA20D11
Hydraulic Power Pack’s Hydraulic Pump
Make : Sumitomo Precision Prod. Co. Ltd.
Model : QT-42-31.5H-S1010-A
Power Pack’s Hydraulic Pump
Make : Daikin Industries Ltd.
Model No. : V15A 2RX-95
Hydraulic Power Pack Unit
Make : Kawasaki Heavy Industries Ltd.
Item : 30/31 Pump Unit
Hyd. Pump : K3VG112
Pressure : 20.6 Mpa
Rpm : 170
Hydraulic Deck Mooring Winch
Make : Kawasaki Heavy Industries Ltd.
Cap. : 47 kN X 12 M/Min.
